Partner HT

Controlled incorporation of fertiliser into the soil during tillage

Hopper capacity double hopper

2800 L

Transport width

2,84 m

Length

1,19 m

Filling height

1,9 m

Partner HT

Partner FT

The rear hopper Partner HT is a double hopper. Thus, one or two different components can be metered and placed precisely.

Easy entry into the sector of placed fertilisation

Compact, clearly arranged rear hopper

Double hopper with a capacity of 2 800 l

Large hopper opening

Pressurised hopper prevents any dust release

Flexibility and variety

Can be combined universally with a lot of HORSCH tillage machines
Easy entry into the sector of placed fertilisation
Pressurised hopper prevents any dust release
Double hopper with a capacity of 2 800 l

HORSCH metering system / HORSCH rotors

• Exact application

• Optimum seed distribution

• HORSCH rotor selection – find the optimum rotor for your machine quickly and easily

• Depending on the components, seed rate and operational speed, various options can be selected

• Easily accessible

• Rotor shafts can be replaced without any tools

HORSCH rotors provide high flexibility and precision for pneumatic seed drills, offering various configurations to match specific seed rates and machine setups. A dedicated selection server helps identify the correct rotor, while integrated valves allow for quick, tool-free replacements even when the hopper is full. To ensure optimum distribution and accuracy, HORSCH recommends performing a calibration test for all seeding operations.

Metering unit – injector hopper system with valve

Pressurised hopper system with locking option.

Pressurised hopper system with open valve

Metering unit – pressurised hopper system with valve

Standard metering unit hexagonal shaft drive

Fine metering insert kits

• Perfect for microgranular compounds and fine seeds

• Seed rates of 1.5 kg/ha to 60 kg/ha

• Can be used in every machine with a pressurised hopper

• Fine metering insert kit includes:

• A drive shaft with four possible drive pinions

• Three rotors with different sizes

• Individual spacers depending on the drive shaft

The HORSCH fine metering insert kit offers a flexible, modular solution for precisely applying fine seeds and microgranules across all machines with pressurized hoppers. By swapping interchangeable rotors, spacers, and pinions, users can easily adjust application rates from 1.5 kg/ha to 60 kg/ha, ensuring universal compatibility and simple operation for models like the Partner, MiniDrill, Pronto, and Focus.

Fine metering insert – rotor

Fine metering insert kits for standard metering unit hexagonal shaft

Fine metering insert kits for double metering unit spline shaft drive

Fine metering insert for double metering unit hexagonal shaft

Electric half-width shut-off

• Saving of product being used like seed and fertiliser

• Overlaps on the headlands, on wedges or obstacles are avoided

• Switching the half-width on and off easily via a button in the terminal

• The electric half-width shut-off can be automated with a SectionControl activation.

HORSCH offers optional electric half-width control to complement standard mechanical systems, enabling significant savings on seed and fertilizer. By integrating with SectionControl for full automation, the system eliminates overlaps and overfertilization on headlands and wedges. Whether using one or two distribution towers, this technology optimizes input distribution and reduces operational costs.

Electric half-width shut-off – switching the half-width on and off easily via a button in the terminal

The electric half-width shut-off can be automated with a SectionControl activation.

Avoiding overlaps on the headlands, on wedges or obstacles improves the development of the individual plant and reduces the disease and competitive pressure in these areas

TECHNICAL SPECIFICATIONS

Transport width

2,84 m

Machine height

1,82 m

Length

1,19 m

Weight

1000 kg

Hopper capacity double hopper

2800 (40 : 60 / 1120 : 1680) l

Dimension of feed opening

1.12 x 0.55 each m

Filling height double hopper

1,90 m

DA control devices

3 (1 DA for hydraulic fan direct drive, 2 DA for mounted implement)

Depressurised return flow (max. 5 bar)

Oil quantity hydraulic fan

35 - 45

Implement attachment tractor-side

3-point Cat. II and III/IV

Implement attachment machine side lower link

Cat. III

Implement attachment machine side ball head

K 80

Implement attachment machine side drawbar

Cat. IV - pin Ø 50 mm
